Specifications and Compliance:

• CSA C22.2 No. 208, Fire alarm and signal cable (Type FAS105)
• CSA C22.2 No. 2556 FT4, UL 1685 Vertical-Tray Flame Test
• IEEE 383 & 1202, ICEA T-30-520 (70,000 BTU/hr) Vertical Flame Test rated
• -40°C Cold Bend and -40°C Cold Impact

Applications:

For use in fire alarm, signal, and voice communication circuits indoors.

Refer to Section 32 of the Canadian Electrical Code for conductor size restrictions.

For non-combustible construction and plenum areas per CE Code Part 1 Appendix G and the National Building Code 1995 Edition Articles 3.15.17 and 3.6.4.3.

For use in ventilated, non-ventilated and ladder-type cable trays

For dry locations, in ceiling air-handling plenums, exposed and concealed wiring.
